The desire to describe colors in a more precise way than we can verbally has been around for many years. In recent years, especially, as industrialization has grown - and with it the degree of specialization - ways and systems of defining colors independently of subjective perceptions have had to be found.
Wilhelm Ostwald, Professor of Physical Chemistry in Leipzig, developed a color system based on physiological perceptions and published it for the first time in 1917. The American painter Munsell also created a color system based on perception.
Both systems contradict the color teachings of the grand master, Goethe, who created his on the basis of color mixtures. His representation of the color circle is incorrect, since the relationships between the colors are not based on perception, but rather on physical mixing attempts.
In 1888, Ewald Hering published his "Lehre vom Lichtsinn ('A doctrine on the sense of color')", in which he set out the theory of opposing colors. According to this theory, red cannot be greenish and green cannot be reddish. Equally, blue cannot be yellowish and yellow cannot be blue-ish. These theories correspond to our perception of color, which is described physiologically but not physically. Ostwald and Munsell also graded their color systems numerically, allowing a precise description of each color. Their color systems also formed the basis of the first international color standard, which was published in 1931 by the CIE (Commission Internationale de l´Éclairage). With some modifications and improvements, the CIELAB system is still used all over the world today, and has more or less become established as a standard in practice.
The growing proportion of aluminum pigments used for manufacturing so-called "metallic" colors, especially in the automotive sector, gave rise to the need to create a precise and adequate method for describing and defining these colors and effect, as well. The previous methods of measuring bright colors with one geometry based on the angle of illumination and observation evolved to produce the multi-angle measurement.
This multi-angle measurement was based on the optical properties of aluminum pigments, which reflect light falling on them like a mirror. The intensity of the reflection diminishes as the glancing angle increases. Consequently, it was possible to measure using a fixed angle of illumination with varying differential angles to the glancing angle. 15°, 25°, 45°, 75° and 110° were defined more or less arbitrarily as the differential angles.
From this portfolio of differential angles, automobile paint manufacturers have selected the appropriate combination for their refinishing sections. As interest also grew in the OEM sector, automobile manufacturers defined their angle combinations, which they then set down as conditions of supply.
When interference pigments such as Iriodin were first introduced to the automotive world in the 1980s, the same measuring geometries were used to define and describe them, but without taking account of their optical characteristics. Only the newer types, such as XillaMaya or ChromaFlair forced users to look more carefully at the issue of optical characteristics, which in the world of physics are known as 'interference'. This refers to the selective reflection of rays of light. When these rays of light meet the surface of a pigment, some of the light is reflected back directly onto the surface. The remaining light passes through the highly graduated layer of refraction and is again partially reflected on the next layer (e.g. glimmer, mica). This part exits the pigment parallel to the first part, which causes interaction between the two known as interference. Due to the different paths that the two parts take, their wavelengths are pushed up against each other. If one wave peak then collides with the other wave peak, the resulting wave is accentuated. It weakens accordingly if a wave peak collides with a wave trough. This selection is known as interference. The resulting color is mainly dependent on the materials' refraction index, the thickness of the layer and the angle of incident light. The two first components can only be defined when the pigments are being manufactured. Only the latter component, the dependence of the angle of incident light, can be influenced by the user and changed.
Using transparent interference pigments, it can be demonstrated that interference can be documented up to 20° from the glancing angle. The area between 20° and 30° describes the transition from interference to the scattering of an effect pigment. The measuring results at differential geometries of 45°, 75° and 110° are therefore primarily influenced by a color's absorbing and scattering component.
The American standardization body ASTM published its "Standard Test Method for Multiangle Color Measurement of Interference Pigment" E2539 in 2008. This divides the geometries into two groups: One group encompasses the geometries that must be used to measure aluminum pigments and corresponding applications. They are termed "aspecular" and are based on the relationship between differential angles to the glancing angle. Geometries that lie between the incident light and the corresponding glancing angle are given a positive mathematical sign. Differential angles on the side of the glancing angle that lies opposite to the incident light are given a negative mathematical sign. Positive angles can also be termed "cis" angles, and negative ones as "trans" angles.
While the measurements are performed for the first group with fixed illumination and varying differential angles, the second group's interference geometries are defined with varying angles of illumination and a fixed differential angle. However only a few measuring instruments have two or more sources of illumination for measuring interference. Newer, portable measuring equipment uses the -15° differential angle. It allows metallics and silver-white interference pigments to be distinguished from colorful interference pigments and their applications.

Measurement Geometries

For many users, the angle specifications on the measuring instruments are often hard to comprehend. Starting with an illumination angle of 45°, the portable devices measure at 15°, 25°, 45°, 75° and 110° from göloss. This lies -45° from the normal. The negative sign is physically not entirely accurate, since the optical law

angle of incidence = angle of reflection

holds true.
The aspecular geometries are calculated from gloss. As such, the specified angle of 15° actually means that the measurement takes place 15° from gloss and thus is conducted at -30°.

A new addition is the -15° geometry, which is measured behind gloss, in the "trans" position. Together with the +15° geometry, thus the "cis" position, the reflection curves can be used to analyze whether this is a coating formulation with color interference pigments or with white interference- or aluminum pigments.

Interference pigments - and with them, pigmented paints or plastics as well - can only be measured at an angle close to gloss. A reversal from the reflection color to the transmittance color takes place in the area between 20° - 30° from gloss. In simple terms, this means that the interference color most heavily influences the total color impression near gloss, while the absorbing portions determine the total color impression further from gloss.
This example shows pearl green on a gray background. The form of the reflection curve switches between 25° and 45°: That is the switch from the reflection to the transmittance.

The law of interference shows the dependency on the angle of the illumination: The flatter an illumination is, the more the color shifts towards the short wavelength. In this chart, the interference line connects the measuring points at different illumination angles. The gray line shows the values that are measured with the portable instruments.

Tactical Aspects for creating OEM Paints

Coating formulations of current OEM series paints generally consist of three different pigment types: Colored pigments that partially absorb incident light and scatter the rest in all directions, aluminum pigments that directly reflect light, and interference pigments that selectively reflect the light.
The present challenge consists of finding a way to combine these three types in a skillful manner. Should the colored pigments and with that, the scattering portions, be in the foreground? Or should, for example, the sparkle impression of the series paint be given a special tone and characteristic? In creating a modern OEM color, knowledge about the angle-dependent effects is important: Current portable measuring instruments are not entirely adequate for meeting the physical demands of measuring interference effects. With visual observation, geometries that also do not describe interference effects are often captured in a window or in a light booth.

Red Sparkle

XillaMaya pigments, especially XillaMaya Crystal Silver, are characterized by the special effect caused by their sparkle. This effect is not physical, but rather defined as a perception. Various companies and institutions have joined together to form a network called "Red Sparkle" in order to conduct research and exchange research results. ASTM (American Society for Testing and Materials) - the standardization committee that is America's equivalent to DIN, the German Institute for Standardization - established the topic of "Sparkle" as a task group.
